| Liandong-u-Gu 17-2#, Shengyuan-Road 1#, Jiangkou-Straat, Fenghua-District, Ningbo-Stad, Zhejiang-Provincie, China | airwolf@flyautomatic.com |
 |
| Plaats van herkomst: | China |
| Merknaam: | FESTO |
| Modelnummer: | DGC-12-600 - G-P-A |
| Min. bestelaantal: | 1pc |
|---|---|
| Prijs: | EXW USD300-400 |
| Verpakking Details: | Plastic zak, Karton |
| Levertijd: | 7-10working dagen |
| Betalingscondities: | T/T, Western Union, Paypal |
| Levering vermogen: | 20 PCs per maand |
| Type: | DGC-12-600 - G-P-A | Artikelnummer: | 530907 |
|---|---|---|---|
| Merk: | FESTO | Zuigerdiameter: | 12 mm |
| Opzettende positie: | Facultatief | Materiële verbindingen: | POM-TPE-U (PU) |
| Hoog licht: | Linear Drive Double Acting Pneumatic Cylinder,530907 Pneumatic Air Cylinders,12mm Piston Pneumatic Air Cylinders |
||
About product
Basic design, plain or ball bearing guide, guide axis without actuator
All settings accessible from one side
Available with variable end stops and intermediate position module
Compact – installation length relative to stroke
Loads and devices can be directly mounted on the slide
Long strokes with no restrictions
Virtually no leakage
Technical Data
| Piston diameter | 12 mm |
| Mounting position | optional |
| Guide | Basic guide Recirculating ball bearing guide |
| Position detection | Via proximity switch |
| Operating pressure | 0.25 MPa ... 0.8 MPa |
| Operating pressure | 2.5 bar ... 8 bar |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Type of mounting | With accessories |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | POM TPE-U(PU) |
Package picture
